Stream: theory: category theory

Topic: Dinatural category of elements

Patrick Nicodemus (Mar 26 2025 at 14:28):

A colleague of mine (who I'm not sure is on this server, so I'm asking on their behalf) came up with/discovered an interesting construction.

Let $F : \mathcal{C}\times\mathcal{C}^{\rm op}\to\mathbf{Sets}$ be a functor. The "dinatural category of elements" of $F$ is the category whose objects are pairs $(c, x)$ with $x\in F(c,c)$. A morphism $(c,x)\to (d,y)$ is $f : c\to d$ such that $F(f,1)(x) = F(1,f)(y)$. Composition and identities are clear. This is equipped with a projection functor $\pi : \mathrm{el}(F)\to C$, but it is apparently not a discrete fibration like the usual category of elements. The connected components of $\mathrm{el}(F)$ correspond to elements of the coend of $F$, similarly to how the colimit of a presheaf is the set of connected components of its category of elements. The set of sections of $\pi$ in $\mathbf{Cat}$ correpond to elements of the end of $F$, similar to how sections of the discrete fibration of the category of elements of a presheaf correspond to elements of the limit of $F$.

Can others elaborate on this? Does it have a name?

Patrick Nicodemus (Mar 26 2025 at 14:36):

I also observed that for any functor $G : \mathcal{A}\times\mathcal{A}^{\rm op}\to \mathcal{B}$ and $b \in B$ one can form a "dinatural comma category" whose objects are pairs $(a, f : G(a,a)\to b)$, a morphism $(a, f)\to (a',f')$ is a morphism $g : a \to a'$ such that $f\circ G(g, 1)=f'\circ G(1,g)$. This "dinatural category of elements" is a particular example of this construction applied to the (ordinary, usual) Yoneda embedding $y : \mathcal{C}^{\rm op}\times\mathcal{C}\to [\mathcal{C}\times\mathcal{C}^{\rm op};\mathbf{Sets}]$. So, this leads me to ask whether there is some specialization of the theory of 2-categories which allows for such "dinatural comma categories" to be expressed as a 2-limit in some way.

Patrick Nicodemus (Mar 26 2025 at 14:41):

Taking the discussion in a somewhat orthogonal direction, just as the "category of elements" construction for a presheaf can be generalized to the Grothendieck construction for indexed categories, it is clear how to generalize this construction to give a "dinatural Grothendieck" construction for functors $F : \mathcal{C}\times\mathcal{C}^{\rm op}\to\mathbf{Cat}$, so if anyone wants to comment on that, feel free

Andrea Laretto (Mar 26 2025 at 15:07):

I also very recently stumbled upon the very same definition! The main problem that left me a bit dissatisfied with this definition is that you do not ever talk about morphisms between $x$ and $y$ in any fiber, and this is obviously connected to the problem that given a morphism $f : c \to d$ one cannot directly relate $P(c,c)$ and $P(d,d)$... so possibly a more enlightened 2-categorical definition might include some sort of laxity instead of the "wedge-like" equation.

Amar Hadzihasanovic (Mar 26 2025 at 15:11):

Just another way you can see this category.
In general, given a functor $\pi: \mathcal{C} \to \mathcal{D}$, one can consider a category of sections of $\pi$, whose

• objects are sections of $\pi$, that is, functors $s: \mathcal{D} \to \mathcal{C}$ such that $\pi \circ s = \mathrm{id}_\mathcal{D}$,
• morphisms from $s$ to $t$ are natural transformations $\alpha: s \Rightarrow t$ such that, for all objects $d$ of $\mathcal{D}$, $\pi(\alpha_d) = \mathrm{id}_d$.

Let $\mathbb{N}$ denote the monoid of natural numbers with addition, seen as a category with a single object.
An endo-profunctor $F$ on $\mathcal{C}$ determines and can be reconstructed from a functor $\pi_F: \mathcal{C}_F \to \mathbb{N}$, where

• $\mathcal{C}_F$ is obtained by adjoining a morphism $x: c \to d$ to $\mathcal{C}$ for every element $x \in F(c, d)$, and quotienting by the equations $gxf = y$ whenever $F(g, f)(x) = y$,
• $\pi_F$ is defined by $\pi_F(f) = 0$ if $f$ is a morphism in $\mathcal{C}$ and $\pi_F(x) = 1$ if $x$ is an element of the profunctor.

Then an equivalent description of your "dinatural category of elements" is the category of sections of $\pi_F$.

Amar Hadzihasanovic (Mar 26 2025 at 15:19):

Notice that “endo-profunctors” are essentially equivalent to “categories over $\mathbb{N}$”; every endo-profunctor determines a category over $\mathbb{N}$ the way that I described, and, vice versa, every functor $\pi: \mathcal{D} \to \mathbb{N}$ determines a profunctor $F_\pi$ on the subcategory $\pi^{-1}(0)$ of $\mathcal{D}$, by letting $F_\pi(c, d) \coloneqq \{ x \in \mathcal{D}(c, d) \mid \pi(x) = 1 \}$, with the action determined by morphism composition in $\mathcal{D}$.
The two constructions are inverse to each other up to natural isomorphism.

Amar Hadzihasanovic (Mar 26 2025 at 15:23):

This is sometimes a nice perspective because it shows you that a “category together with an endo-profunctor on it” can be faithfully encoded as the data of a “category [but a different one!] together with an $\mathbb{N}$-valued, additive measure on its morphisms”.

Amar Hadzihasanovic (Mar 26 2025 at 15:28):

Then your category of sections has, as objects, objects of this category together with a measure-1 endomorphism on them; this may sometimes be interpreted as a category of dynamical systems...

fosco (Mar 26 2025 at 15:32):

I see this story from a slightly different point:

• A monad in profunctors is a category
• A mere endo-1-cell in profunctors is a (directed) graph

In such directed graph, you can study iterated compositions of the profunctors with itself, studying "flows" of the discrete dynamical system prescribed by the endo-profunctors.

Amar Hadzihasanovic (Mar 26 2025 at 15:33):

Amar Hadzihasanovic said:

Notice that “endo-profunctors” are essentially equivalent to “categories over $\mathbb{N}$”; every endo-profunctor determines a category over $\mathbb{N}$ the way that I described, and, vice versa, every functor $\pi: \mathcal{D} \to \mathbb{N}$ determines a profunctor $F_\pi$ on the subcategory $\pi^{-1}(0)$ of $\mathcal{D}$, by letting $F_\pi(c, d) \coloneqq \{ x \in \mathcal{D}(c, d) \mid \pi(x) = 1 \}$, with the action determined by morphism composition in $\mathcal{D}$.
The two constructions are inverse to each other up to natural isomorphism.

Sorry, this is not true, lol --- it is true that $\pi \mapsto F_\pi$ is a left inverse of $F \mapsto \pi_F$, but not the other way around

fosco (Mar 26 2025 at 15:34):

Indeed, I was starting to express doubt about it. Not categories over NN...

Amar Hadzihasanovic (Mar 26 2025 at 15:36):

Yes I was thinking about the (true) fact that profunctors = categories over the arrow and I turned it too hastily into endo-profunctors = categories over the loop, but it's only an “inclusion” in the latter case.

Amar Hadzihasanovic (Mar 26 2025 at 15:48):

I'd hasard the conjecture that endo-profunctors = categories with a strict Conduché functor to $\mathbb{N}$...

Amar Hadzihasanovic (Mar 26 2025 at 15:55):

Thus Conduché functors into B correspond to pseudofunctors from B, regarded as a locally discrete bicategory, to the bicategory Prof.

Well this seems to confirm it, since pseudofunctors from $\mathbb{N}$ to $\mathrm{Prof}$ classify endo-profunctors.

Amar Hadzihasanovic (Mar 26 2025 at 16:15):

So my intuition is that a Conduché functor $\mu: \mathcal{C} \to \mathbb{N}$ is like a measure on morphisms of $\mathcal{C}$ that is additive wrt composition, and with the property that every morphism of length $n$ can be decomposed into $n$ morphisms of length $1$; this is the sort of thing that seems quite natural in modelling some categories of discrete-time processes

Mike Shulman (Mar 26 2025 at 16:16):

I think the "standard" construction that this is most closely related to is the "two-sided category of elements", which associates to any profunctor $C\nrightarrow D$ a [[two-sided discrete fibration]] $C \leftarrow E \to D$, which is a fibration over $D$ and an opfibration over $C$, compatibly, and discrete over $C\times D$ (but not over $C$ or $D$ individually). Then if it should happen that $C=D$, you can pull back along the diagonal $C\to C\times C$ and I think you get your construction.
